Jinko Neo N-type 72HL4-BDV 570w,575w,580w,585w,590w
Module number:Jinko Neo N-type 72HL4-BDV570-590 Watt
Weight:31 kg
Package:36pcs/pallet;720pcs/40hq
Specification:2278×1134×30mm
Trademark:Jinko solar
Origin:China
Product Details
| Mechanical | Characteristics | |
| Cell Type | N type Mono-crystalline | |
| No.of cells 144(2×72) | ||
| Dimensions 2278×1134×30mm (89.69×44.65×1.18 inch) | ||
| Weight 32 kg (70.55 Ibs) | ||
| Front Glass 2.0mm,Anti-Reflection Coating | ||
| Back Glass 2.0mm,Heat Strengthened Glass | ||
| Frame | Anodized Aluminium Alloy | |
| Junction Box | IP68 Rated | |
| Output Cables | TUV 1×4.0mm³ (+):400mm,(-):200mm or Customized |
Length |
Product Description
AKS Jinko Neo N-type 72HL4-BDV Solar Panel 570W 575W 580W 585W 590W Bifacial Module Dual Glass Jinko Solar Solarpanel
Certifications and Standards: Jinko Solar panels typically adhere to international standards and certifications, including IEC, TUV, UL, and others. These certifications validate the quality, safety, and performance of the panels, providing assurance to customers.
Installation Versatility: The Tiger Neo N-type panels are designed for easy integration into various solar installations. Whether it's a rooftop, ground-mounted, or solar farm system, these panels offer flexibility and compatibility with different mounting options.
SMBB Technology
Better light trapping and current collection to improve module power output and reliability
Hot 2.0 Technology
The N-type module with Hot 2.0 technology has better reliability and lower LID/LETID.
PID Resistance
Excellent Anti-PID performance quarantee via optimized mass-production process and materials control.
Enhanced Mechanical Load
Certified to withstand: wind load (2400 Pascal) and snowload (5400 Pascal).
Higher Power Output
Module nower increases 5.25% aenerally brinaina significantly lower LCOE and higher IRR.
